WIRE
LARGE STOCK - READY TO SHIP
Titanium Wire & Rod
Standard Titanium produce and supply titanium wire, rod and filler rod products. Wire and rod is available in Grades 1-4 CP titanium along with titanium alloys. ERTi-* welding filler rods in a range of size. Wire is available as spooled, straight and coiled form. Stock program is produced to AWS A5.16 and ASTM B863 standards.
Welding Filler Material
ERTi-* Filler rods and wires conform to:
- AWS A5.16: Specification for titanium and titanium-alloy welding electrodes and rods.
- ASTM B863: Standard specification for titanium and titanium-alloy welding wire.
All of our titanium spooled wire, titanium coiled wire, titanium straight wire are available in a variety of different surface finishes including pickling, black painted and sand blasted.
Production Capability
- Production Standard: AWS A5.16, ASTM B863
- Grades: Grade 1 – 4, Ti 6Al-4V, Ti 6Al-4VEli, Ti 0.2 Pd, Ti 3Al-2.5V, Ti 0.3Mo-0.8Ni
- Welding Filler Rods: ERTi-2 ERTi-5
- Wire Dimensions: Diameter 0.05 – 6 mm, Length – Spools: 100mm – 300mm – Straight: 300mm – 3000mm,
- Wire Types: Wire Coil, Wire Spool, Straight Rod
Titanium Wire Dimension Ranges and Forms
Available Titanium Wire Dimensions and Forms
| Diameter mm | Diameter inch | Coil | Spool | Straight |
|---|---|---|---|---|
| 0.05 to 0.78 | 0.002 to 0.031 | Y | Y | N |
| > 0.78 to 3.25 | > 0.031 to 0.128 | Y | Y | Y |
| > 3.25 to 6.00 | > 0.128 to 0.236 | Y | N | Y |
Titanium Wire Standards
Titanium wire grades to the corresponding manufacturing standards
| Grade | AWS A5.16 | ASTM | AMS |
|---|---|---|---|
| Commercial Pure Titanium | ERTi-1,2,3,4 | ASTM B863 Gr1,2,3,4 | AMS 4951 |
| ASTM F67 Gr1,2,3,4 | AMS 4921 |
||
| Ti 6Al-4V | ERTi-5 | ASTM B863 Gr5 | AMS 4954 |
| Ti 6Al-4V Eli | ERTi-5 Eli | ASTM B863 Gr23 | AMS 4956 |
| ASTM F136 Eli | |||
| Ti 0.2 Pd | ERTi-7 | ASTM B863 Gr7 | |
| Ti 3Al-2.5V | ERTi-9 | ASTM B863 Gr9 | |
| Ti 0.3Mo-0.8Ni | ERTi-12 | ASTM B863 Gr12 |
